MIL-T-21869/37F
1 December 1989
SUPERSEDING
MIL-T-21869/37E
13 January 1984
MILITARY SPECIFICATION SHEET
TRUCK, LIFT, FORK, ELECTRIC, SOLID TIRES,
4,000 POUND (1820 KILOGRAMS) CAPACITY, 180 INCH (4570 MILLIMETERS) LIFT,
GENERAL PURPOSE, TYPE "EE"
TRIPLE STAGE MAST
The complete requirements for procuring this truck described herein shall consist
of this document and Specification MIL-T-21869, Trucks, Lift, Fork, Electric,
Sit-Down, Front Wheel Drive, Rear Wheel Steer, General Specification For, dated
13 January 1984.
4,000 LbS. (1820mm) at
Capacity
1.
24 inches (610mm) load center
84 inches (2130mm) (maximum)
2. Collapsed mast height
180 inches (4570mm) (minimum)
3. Fork height
47 inches (1200mm) (minimum
4. Free lift height
1.8 in. (501mm) thick (maximum)
5. Fork size
5.06 in. (130mm) wide (maximum)
40 in. (1020mm) long + 0" (0mm) 1/2"
-(12mm)
38 inch (960mm) spread (minimum)
6. Fork spacing (measured between
12 inches (300mm) together (maximum)
outer edges of forks) :
8,000 Lbs. (3640 Kg.)
7. Static overhead guard test load
84 inches (2130mm) (maximum)
8. overhead guard height
150 Lbs. (670N) for nonpower and
9. Tangential steering force at rim of
25 Lbs. (110N) for power steering
hand wheel
142 inches (3610mm)
10. Right angle turn, dimension "A"
(add 4 inches (100mm) when side shifter attachment is used)
25 feet (8m) per minute (minimum)
11. Lifting speed
27 feet (8m) per minute (minimum)
12. Lowering speed
5 to 8 miles (8 to 13 kilometers)
13. High drive speed
per hour
15 percent slope (8.5 degrees)
14. Slope ascension
15. Stability to be in accordance with
ANSI//ASME B56.1
(2 degrees +/- 0.5 degree)
16. Upright tilt: Forward
(6.5 degrees +/- 0.5 degree)
Rearward
